SERVO MOTOR DE CA YASKAWA SGMPH-15AAA2C SERIE SIGMA-II

Product parameters

Model: SGMPH-15AAA2C

Series: Sigma-II SGMPH series

Rated output power: 1.5kW (1500W)

Rated speed: 3000 RPM

Maximum rotational speed: 5000 RPM

Rated torque: 4.77 N·m

Instantaneous maximum torque: 14.3 N·m

Rated current: 9.2A

Instantaneous maximum current: approximately 28 A

Power supply voltage: Single-phase/three-phase AC 200 V, 50/60 Hz

Encoder: 13-bit incremental encoder (2048 x 4 resolution, approximately 8192 ppr)

Insulation class: B grade

Protection grade: IP67 (Except for the parts through which the shaft passes, fully enclosed self-cooling type)

Vibration level: V15

Insulation resistance: DC 500 V, 10 MΩ or above

Insulation withstand voltage: AC 1500 V, 1 minute (200 V class)

Environmental conditions: Operating environment temperature: 0°C to +40°C Storage temperature: -20°C to +60°C

Environmental humidity: 20% to 80% (no condensation)

Rotor inertia: Medium inertia, suitable for dynamic load matching

Shaft end design: Straight shaft without keyway

Others:

Excitation method: Permanent magnet type

Installation method: Flange installation

Accessories: No brakes, no oil seals (standard configuration)

Function

High torque-length ratio It offers a rated torque of 4.77 N·m and an instantaneous maximum torque of 14.3 N·m, making it suitable for high dynamic loads. The design of medium-inertia rotor optimizes load matching and enhances response speed.

High-precision positioning: Equipped with a 13-bit incremental encoder (8192 ppr), it supports high-precision position control.

Wide speed range: Rated speed 3000 RPM, maximum speed 5000 RPM, suitable for high-speed and medium-speed applications.

High protection performance: IP67 protection grade (except for the shaft end), suitable for dusty or slightly splashed water environments.

Vibration suppression: Supports vibration tolerance up to 49 m/s² to ensure smooth operation.

Compatibility Seamlessly integrated with Yaskawa Sigma-II series servo drives. Supports torque, speed and position control modes, which can be switched through driver parameters.

Easy to maintain Serial encoders reduce wiring complexity (with half the wiring compared to traditional encoders). The main circuit is separated from the control circuit, which is convenient for troubleshooting.

Energy conservation and efficiency Permanent magnet excitation and efficient design reduce energy consumption. With the appropriate driver, achieve smooth and highly dynamic operation.

Application scenarios

PCB drilling machine: High speed and precise position control, meeting the requirements of high-speed drilling.

Industrial robots: Used for robot joint drive, providing rapid response and high torque output.

Conveyor belt system: Drives the automated conveyor belt to ensure smooth and efficient material handling.

Packaging equipment: Applied to high-speed packaging machines, sealing machines and labeling machines, meeting the requirements of dynamic load.

CNC machine tools: Used for high-precision milling and turning, providing stable torque and speed control.

Printing machinery: Drive printing machines or die-cutting machines to ensure speed synchronization and positioning accuracy.

Textile machinery: Used in high-speed looms or spinning machines, providing low vibration and stable operation.

Other automated equipment: Suitable for automated production lines that require compact design and high torque, such as assembly lines or testing equipment.
